Brand Parts
♦BYHX/HOSON Boards
♦Japan THK 30mm low noise guide rail with dual slider
♦Japanese Fuji 400W servo motor
♦Automatically lift type carriage
♦Italy Megadyne belt
♦Bulk ink supply system
♦Hard oxidic vacuum adsorption platform
Features
♦Strong and high quality printer body.
♦Aluminum beam.
♦Automatic cleaning and wiping system.
♦Full steel print head,printing speed is excellent,with flushing function,avoid heads blockage.
♦The temperature of the front and back heating system can be ajusted by intelligent PID controller.
♦Constant temperature negative pressure ink supply system,supports the solvent printer print in the
high speed and in a cold environment.
♦Allow you to change the parameter of step,double direction,and speed while printing.
♦Automatically skip the white area of printing,make higher effective
♦Automatically feed in and take up system
♦Precise steel belt driving mode
Your Right Choice Of Printer And Media Manufacturders
Configures
Printer Type: Solvent 3200
Max Print Width: 3.2m
Printer Head: Knoica 512i
Print Color: CMYK LC LM
Head Number: 4pcs/6pcs/8pcs(optional)
Maxmium Speed: 260sqm/hour (8pcs head 2pass)
Parameter
|
Machine Type |
Economic Solvent Printer |
|
Print technology |
Drop-on-demand Piezo electric |
|
Resolution |
1440dpi (max) |
|
Max Print width |
3.2m |
|
Ink Model |
Solvent/two year outdoor liftime |
|
Print Speed |
2pass:260sqm/h; 3pass:140sqm/h; 4pass:98sqm/h |
|
Color |
CMYK LC LM |
|
Media handle |
Roll to roll |
|
Drying system |
Heater/Fans |
|
File format |
TIFF,Postscript3,JPEG,EPS,PDF |
|
Working process |
DPCS/pRINTMON software for windows xp/windows 7 |
|
Vacuum Table |
hard oxydic vacuum adsorption platform.mechanical drive |
|
Rip |
Photoprint/Maintop/Printfactory |
|
Power supply |
50hz/60hz ,220V (10%)20A |
|
Operation environment |
Temperature 18℃-26℃ Humidity 40%-70% |
|
Dimension |
4.6m*0.9m*1.55m |
|
Weight |
900kg |
|
Media |
Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics, paper,ect |
Applications & Media
Media: Flex banner,vinyl sheet,one way vision,mesh,PVC fabrics,paper,ect
Enchosure advertising,Wall,Wrps,HD advertising.
Busbody,Building,Anti-aircraft,Glass screenadvertising
Packaging & Shipping
Services
♦ Customized Service: We Can Provide Customized Production and Packing For You!
♦ Warranty: The warranty is one year!
♦ Print Service: We Also Provide FREE Printing Samples For You!
♦ Training Service:Provide FREE Training for Our Clients! Even can Send Engineer to Oversea local customer for onsite service and training, provide suppport on installation
and operation.
♦ Solution Service: We Have Digital Printing Solution Ability!
♦ Online support: Through Skype, Whatsapp,Wechat,or TeamViewer contact
with customers.
