Product Description Import THK Guide rail and slider

Anti-noise aluminum guideline ,very durable and stable.

i3200 U1/A1 heads
Support the UV/ water-based inkcan be used for various flexy material :leather,pp paper,car sticker etc . also can be used for KT board ,foam board,glass, metal, wood, ceramic etc Intelligent ink alarm system The device will alarm when the ink level is below the warning line.

Intelligent Anti-collision device is adopted to protect the printing heads

 Hybrid UV printer
Max printing size185c m
Max printing resolution2440dpi*3200dpi
Printheadi3200 U1/i3200A1/i3200E1
UV ink colorCMYKW V
Drying system UV Led
Max printing thickness10 cm
Ink consumption15-20ml/ sqm
Cooling MethodcoldlyWater cycling Cooling system
Lamp typeLED Lamp (saving energy and environmental friendly)
Ink systemCISS built inside
Height adjustmentAutomatic with sensor.
Driving power220 V
Working environment20-35C , Humidity : 15% -25%
suction systemEquipped
Image formatTiff, Bmp , Jpg,Eps,Pdf,CAD
Rip softwareprintfactory
Printing materialRigid PVC board, glass, plastic, organic board, leather, rubber, special paper, metal, wood, porcela
Printing speed16 m2/h (4 pass )10 m2/h ( 8 pass )8 m2/h ( 12 pass )
Machine weightPacking weight850kg1000 kg
Packing size373*126*166 cm
Printing Sample Show EXHIBITION SHOW Company Information
