Product Description
Specification
| Product Model | YC2513R | ||||||
| Printhead Type | RICOH GEN5/GEN6/KM1024I/SPT1024GS | ||||||
| Printhead Number | 3-8 heads | ||||||
| Ink Characteristics | UV Curing Ink (VOC Free) | ||||||
| Ink reservoirs | Refillable on the fly while printing 2500ml per color | ||||||
| LED UV Lamp | more than 30000-hours life made in Korea | ||||||
| Printhead arrangement | CMYK LC LM W V Optional | ||||||
| Printhead Cleaning System | Automatic Cleaning System | ||||||
| Guide rail | TAIWAN HIWIN/THK Optional | ||||||
| Working Table | Vacuum Sucking | ||||||
| Printing Size | 2500*1300mm | ||||||
| Roller Material Width | 2500mm | ||||||
| Roller Material Diameter | 200mm | ||||||
| Print Interface | USB2.0 | ||||||
| Media Thickness | 0-100mm | ||||||
| Life of printed image | 3 years(outdoor),10years(indoor) | ||||||
| Print Resolution | 720*600dpi, 720*900dpi, 720*1200dpi | ||||||
| File Format | TIFF,JPEG,Postscript,EPS,PDF etc. | ||||||
| RIP Software | Photoprint Ntek Edition | ||||||
| Power Supply | 220V 50/60Hz(10%) | ||||||
| Power | 8500W | ||||||
| Operation Environment | Temperature 20 to 30 ℃,Humidity 40% to 60% | ||||||
| Machine Dimension | 4.57*2.98*1.46m | ||||||
| Packing Dimension | 5*2.25*1.55m 3.2*0.85*1.1m | ||||||
| Weight | 2000kg | ||||||
| Warranty | 12 months exclude the consumables related to ink, such as ink filter, damper etc | ||||||
Company Profile
Linyi Win-Win Machinery Co., LtdLinyi Win-Win Machinery Co,. Ltd.is founded in 2009 in Shandong China. The Enterprise is a high-tech machinery manufacturer,integrated with the R&D, production,sales, and maintenance in a whole. We mainly manufacture UV flatbed printers,UV flatbed with roll to roll, UV hybrid printer, all products are with CE certificate. Ntek is the pride of Chinese national industry, It has become one of Chinese top 20 enterpises for producing UV printer in China. we are one professional manufacturer of UV printing machine in China. Our flatbed printing machines are with high resolution, high technology and competitive price, and our machines have won widespread praised and recognition by our customers all over the world. We are one leading manufacturer, supplier and exporter of UV printing machine in China, we only produce UV printer. So compare to other factories, we are more professional. we supply to decoration industry, advertising industry, signage industry, glass industry, acrylic industry, wood industry, ceramic industry, ect. We endeavor to serve the needs of our customers and agents, by continually developing innovative technologies, we strive to create products and service to improve people's life. Welcome for business negotiation.
Packing & Delivery
FAQ How long does the printing images will last outdoors and indoor?The printing images can last at least 3 years outdoors, and more than 10 years indoor.
What is the cost of ink for printing on the materials?
Normally it is around 0.5-1usd per square meter for ink cost.
How about the stability and quality of the printing images?
This UV flatbed printer can used to print on most of medias with best quality, durability, best result.
How about the maintance and after sales service?
Our engineer available service overseas, and we can provide remote control service and online service for customers. But customer has to be responsible for the accommodation and transportation costs of the technical staff.
Are you a manufacturer or trade agent?
We are the manufacturer of UV flatbed printers.
Is there any guarantee for this printer?
Yes, we have guarantee for the printer. We provide 13 months warranty for all the electronic parts including the main board,
driver board, control board, motor, etc, except the consumables, such as ink pump, printhead, ink filter, and slide block etc.
How can I install and start to use the printer?
Normally we will arrange technican for installation and training in your factory. or you can read the users' manual to understand
the machine. If you need any help, our technician can help you via Teamviewer. Whenever you have questions to the machine, you can
contact our technician or me directly.
Can I get supplies and wearing parts from you?
Yes, we provide all the wearing parts for our printers always and they are in stock.
How will you achieve the warranty?
If any electronics or a mechanical part is confirmed to be broken, Ntek should send the new part within 48hours by express like
TNT, DHL, FEDEX .etc to the buyer. And the shipping cost should be born by the buyer.
What kinds of materials need premier before printing?
Glass, ceramic, metel, acrylic, marble etc Welcome to contact us for a discount or free printing sample printed by our UV printer.
