Consumable materials
DTF pigment ink
1000ml per bottle, CMYKW as one set.
Hot Melt Powder
Each bag 1kg.
DTF Film
Each roll 30cm wide and 100m long. Working process
Application
Product Description
All in one Compact solutionCompact machine size saves shipping costs and space in your shop. An all in one DTF printing system allows for no-error continuous work between the printer and the powder shaker and brings convenience in relocating and re-installing the printer.
The standard version is installed with 2pcs of Epson XP600 printheads, with the extra options of Epson 4720 and i3200 to meet a variety of requirements for output rate.
The CNC vacuum suction table can fix the film in place stably, and prevent the film from bending and scratching the printheads.
The off-line white ink circulation device automatically turns on after the machine is powered off, keeping you away from the worry of white ink precipitation and printhead clog.
The electric cap station automatically raises up/lowers when the carriage returns/leaves, making sure that the printheads are sealed and cleaned well, and avoid clogging. Made of durable aluminum alloy, it's corrosion resistant and will last for years. Extra-large pressure roller with increased friction gives better material rolling, making the paper feeding, printing, and taking up more smooth
Two-stage heating for better attachment between the ink and film, and better powdering, which helps to get more vibrant prints. The temperature control precision is as close as 0.1℃.
5pcs of high-quality heating tubes for efficient heating and industrial production. The temperature can be adjusted conveniently in the control panel. Machine/Package Size
The machine will be packed in solid wooden box, suitable for international sea, air, or express shipping.The package size:The printer and powder shaker in one:1.65*1.11*0.93=1.70CBM
Package weight: 230kg Specification
| Model | Nova 30 DTF Printer | ||
| Printing width | 30cm/11.8in | ||
| Print head | XP600/i3200 | ||
| Print head qty.（pcs） | 2pcs | ||
| Suitable media | PET film | ||
| Heating and drying function | Front guide plate heating, solidified upper drying, and cold air cooling function | ||
Printing speed | 5.5㎡/h(standard precision) | ||
| 5㎡/h(midium precision) | |||
| 4.6㎡/h(high precision) | |||
| Printing resolution | 720*4320dpi | ||
| Print head cleaning | Automatic | ||
| Heating method | Front guide plate heating (30-65℃) | ||
| Platform suction adjustment | Available | ||
| Printing interface | USB3.0 | ||
| Working environment | Temperature 20－25℃ | ||
| Relative humidity | 40-60% | ||
| Software | Maintop/ PhotoPrint | ||
| Operating system | XP/Win7/Win10/Win11 | ||
| Rewinding function | Automatic induction rewinding | ||
| Rated power | 250士5%W | ||
| Machine size | 185*99*115cm | ||
| Weight | 190kg | ||
