Product Description Afinia L801 Colour Label PrinterHighest quality for low costs!!!
The easy-to-use L801 Industrial Color Label Printer is powered by Memjet Waterfall Printhead Technology®. Built with a stationary printhead for ultimate speed, and a 1.25 liter ink capacity for large print runs, the L801 saves you both time and money. The L801 Memjet label printer is an industrial web-fed inkjet solution, ideal for short- to medium-range print runs for retail, inventory, and product identification applications. Specification

Print Speed 6 or 12 ips (Inches per second)
Print Type Inkjet
Print Technology Memjet
Print Resolutions 1600dpi at 6ips or 1600 x 800dpi at 12ips
Inks Dye based 5 colour inks
Core Size 3″ (76.2mm)
Label Width 2″ – 8.5″ (50mm – 215.9mm)
Label Length 0.75″ – 20″ (19mm – 508mm)
Inter Label Gap Size 0.125″ – 0.3″ (3.175mm – 7.62mm)
Media/Liner Width 2″ – 8.25″ (50mm – 216mm)
Black Mark Size 0.125″ – 0.3″
Label Thickness 0.004″ – 0.01″ (0.1mm – 0.3mm)
Cutter Powered Cutter
Unwinder 8.5″ (216mm) max width, 8″ (152.4mm) OD on a 3″ core
Overall dimensions18.9" (480 mm) W, 19" (485 mm) D, 21.1" (535 mm) H
Weight83 lb (37.6 kg)
Rated voltageAC 110V – 220V, auto-sensing
Operating Environment
Operating systemWindows 7+ (32 and 64 bit)
Operating temperature:15°–35° C (59°–95°F) at RH 20–80%
2D code printing:2D Barcode at least Grade B (PDF417) with 10mils cell size
Strength Professional Print Quality at High Speeds
The L801’s combination of print quality, speed, and ink cost is tough to beat

The L801 is a Memjet-powered industrial inkjet printer that is ideal for short- to medium-range print runs for prime and secondary labeling applications. It prints on continuous or die-cut stock from 2 to 8.5 inches in width, in full color, and at speeds of up to 60 feet per minute. Super-fine resolution makes for crisp text and barcodes, even at very small sizes.
This detail, combined with vivid colors and rich blacks, makes labels look sharp and vibrant. The L801 is also compatible with a wide range of paper, polyester, polypropylene, and vinyl label stocks.
L801 Details Minimize ongoing ink costs
Cost per label should be as important as printer cost when investing in a label printer. These ongoing costs are minimized by the L801’s industry-leading ink cost, which can be easily calculated using the included software. It holds 1.25 liters of ink to support large runs, and has easy-access doors for fast and simple media and ink replacement. An optional powered rewinder makes printing to finished rolls simple.
Roll-to-roll label printing
Afinia Label L801 Color Label Printer with RewinderThe optional rewinder pairs perfectly with the L801 to allow for continuous, roll-to-roll label production. Easily handle rolls up to 8 inches in outside diameter for high-volume jobs and reduced media costs. It’s a recommended addition for companies that experience high usage or heavy duty jobs.
Like the L801, the rewinder can handle label sizes up to 8.5″ wide and rolls with up to 8.0″ outside diameter. It gives you theability to choose the direction of rotation to situate labels to be either face-in or face-out.
Once rewinding is complete, simply remove the core holder and completed roll.
Memjet Waterfall Technology
The L801 Industrial Color Label Printer is a digital label printer that uses Memjet technology, allowing you to print high-impact, full-color output at up to 60 ft/min (18 m/min). Memjet’s stationary “waterfall” printhead technology allows paper to move quickly through the printer, while maintaining excellent print resolution.
High quality & resolution
Using the L801 industrial color label printer, you can print at up to 1600 x 1600 dpi for vivid, eye-catching labels. By using
CMYKK (two black ink cartridges), the L801 offers exceptional color and rich blacks, giving you the ability to print with better contrast.
Related Products Company Profile
Jinya Intelligent Technology Shanghai Limited is a company that develops and produces self-adhesive materials and self-adhesive labels. The company started from ordinary self-adhesive materials and has been continuously developed into a total solution that can provide professional digital self-adhesive materials. It is widely used in home care, office, food and beverage, cosmetics and other industries.
According to different ink-based methods, Jinya launched the All-inkjet series of digital label stock, which are in the leading position in the industry. It is suitable for UV, laser, thermal transfer, electronic ink and water-based inkjet. From paper to film, from matte to glossy, the All-inkjet range of digital label stock are extremely advantageous to meet your application needs.
Meanwhile, it is suitable for HP indigo, Memjet, Canon, Epson and other brand models.
Jinya's perfect customer service, high-quality production management, and value the needs of end customers are the right choice for your digital printing business. We understand every aspect of digital coating material, from top coating to plastic coating to adhesive coating and laminating. Every step, we constantly innovate and develop, and each step is efficient and stable.All-inkjet digital label stock, print colorful world!
