Big front and back rubber rollers, which makes belt is more stable , and conveyer belt will not running deviation at all.
.magic-0{border-bottom-style:solid;border-bottom-color:#53647a;font-family:Roboto;font-size:24px;color:#53647a;font-style:normal;border-bottom-width:2px;padding-top:8px;padding-bottom:4px} .magic-1{width:750px} .magic-2{overflow:hidden;width:750px;height:93px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-3{margin-top:0;margin-left:0;width:750px;height:93px} .magic-4{vertical-align:top} .magic-5{padding:0;margin:0;color:#333;font-size:14px;padding-left:4px;font-weight:bold;white-space:pre-wrap} .magic-6{text-align:center} .magic-7{font-size:24px} .magic-8{vertical-align:top;display:block;padding-right:4px;box-sizing:border-box;padding-left:4px} .magic-9{vertical-align:top;padding-bottom:4px;box-sizing:border-box;padding-top:4px} .magic-10{padding:0;margin:0;white-space:pre-wrap;font-size:14px} .magic-11{font-size:20px} .magic-12{overflow:hidden;width:247.33333333333334px;height:247.33333333333337px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-13{margin-top:0;margin-left:0;width:247px;height:247px} .magic-14{overflow:hidden;width:247.33333333333334px;height:247.33333333333337px;margin-top:0;margin-bottom:0;margin-left:4px;margin-right:0} .magic-15{width:750px;border-collapse:collapse} .magic-16{min-height:28px;padding:5px 10px;width:132px;min-height:28px;box-sizing:content-box} .magic-17{min-height:28px;padding:5px 10px;width:572px;min-height:28px;box-sizing:content-box} .magic-18{display:none} .magic-19{min-height:28px;padding:5px 10px;width:393px;min-height:28px;box-sizing:content-box} .magic-20{min-height:28px;padding:5px 10px;width:131px;min-height:28px;box-sizing:content-box} .magic-21{min-height:28px;padding:5px 10px;width:159px;min-height:28px;box-sizing:content-box} .magic-22{min-height:28px;padding:5px 10px;width:392px;min-height:28px;box-sizing:content-box} .magic-23{width:446px} .magic-24{overflow:hidden;width:446px;height:250.35466666666667px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-25{margin-top:0;margin-left:0;width:446px;height:594px} .magic-26{width:300px;display:flex;flex-direction:column;margin-right:0;margin-left:4px} .magic-27{font-size:18px} .magic-29{font-family:inherit;font-style:inherit;font-variant-ligatures:inherit;font-variant-caps:inherit} .magic-30{font-size:14px} .magic-31{width:300px;display:flex;flex-direction:column;margin-right:4px;margin-left:0} .magic-32{text-align:left} .magic-33{overflow:hidden;width:446px;height:249.76px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-34{margin-top:-85.632px;margin-left:0;width:446px;height:400px} .magic-35{overflow:hidden;width:446px;height:400px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-36{margin-top:0;margin-left:0;width:401px;height:360px} .magic-37{margin-top:0;margin-left:0;width:446px;height:400px} .magic-38{margin-top:-24.976px;margin-left:0;width:446px;height:594px} .magic-39{background-color:#fff} .magic-40{overflow:hidden;width:750px;height:999px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-41{margin-top:0;margin-left:0;width:750px;height:999px} .magic-42{overflow:hidden;width:750px;height:690px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-43{margin-top:0;margin-left:0;width:750px;height:690px} .magic-44{overflow:hidden;width:750px;height:707px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-45{margin-top:0;margin-left:0;width:750px;height:707px} .magic-46{overflow:hidden;width:446px;height:529.7354097777778px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-47{margin-top:0;margin-left:0;width:590px;height:529px} .magic-48{overflow:hidden;width:750px;height:1052px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-49{margin-top:0;margin-left:0;width:750px;height:1052px} .magic-50{overflow:hidden;width:750px;height:491px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-51{margin-top:0;margin-left:0;width:750px;height:491px} .magic-52{overflow:hidden;width:750px;height:546px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-53{margin-top:0;margin-left:0;width:750px;height:546px} .magic-54{overflow:hidden;width:750px;height:560px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-55{margin-top:0;margin-left:0;width:750px;height:560px} .magic-56{overflow:hidden;width:750px;height:492px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-57{margin-top:0;margin-left:0;width:750px;height:492px} .magic-58{overflow:hidden;width:750px;height:184px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0} .magic-59{margin-top:0;margin-left:0;width:750px;height:184px}
Automatic feeding and take up system
Automatic Height Measurement System
Intelligent Magnetic Secondary ink cartridges
Computer Support
PACKAGE
Products Description
1.8m UV Hybrid Printer
(UV roll to roll printing & UV flatbed printing)
(UV roll to roll printing & UV flatbed printing)
UV hybrid printer, it can print board materials, also can print roll to roll materials, which can print flexible materials such as advertising cloth, reflective film, PVC ceiling fil, leather, canvas etc, also can print board materials, such as glass, ceramic
tile, PVC, aluminum sheet, wood, MDF board, metal panel, billboard, acrylic panel, paper board, foam board, PVC expansion board, corrugated cardboard, bamboo, leather, glass, USB etc.
tile, PVC, aluminum sheet, wood, MDF board, metal panel, billboard, acrylic panel, paper board, foam board, PVC expansion board, corrugated cardboard, bamboo, leather, glass, USB etc.
Product Paramenters
Model | KC-FS1808 | ||
Print Width | 1.8M | ||
Printhead | Ricoh G5i head | ||
Pinthead Quantity | 2-3 pieces (Ricoh G5i heads) | ||
Printhead Height | 1.5mm-50mm optional | ||
Printhead Skill | Piezoelectric inkjet | ||
Ink | Ink | UV ink | |
Type | CMYK/Dual CMYK / CNYKLcLm and white/cmyk+white+varnish | ||
Color | ICC or density curve | ||
Color Gamut | 2000ml | ||
Cartridge capacity | Automatic ink supply | ||
Precision | Ink supply system | ||
Precision | 720dpi*900dpi 720*1200dpi | ||
Speed | 6pass:3-5m² 8pass:1-3m² | ||
Print Media | PVC board, foam board, metal, glass ,ceramic tile, acrylic,TK board,PP,PVC,vinyl ect. All kinds of Board material and roll to roll material | ||
Platform adsorption | 750W Turbo fan | ||
Drying system | UV led | ||
Take-up system | Photoelectric sensor | ||
Rip Software | Photoprint | ||
Operation System | Windows XP /Windows 7 | ||
Power Supply | 50/60HZ,220V(30%)>30A | ||
File Format | TIFF,JPEG(the best file format is TIFF) | ||
Environment | Humidity:40%-60%, Temperature:20℃-28℃ | ||
Machine Size | L*W*H(3300*3300*1400)MM | ||
Package Size | L*W*H(3420*1120*1480)MM | ||
Details Images
Thick Front and Back Rubber Rollers
automatic feeding and take up system are controlled by motors, which make the roll to roll materials more tight and put better during printing.
The printer can measure the media and head height automatically by software control with sensor, which can eliminate the procedure
that we measure thickness by ourselves.
that we measure thickness by ourselves.
Ink intelligent magnetic control by secondary ink cartridges, it is opened when power on the machine, and closed when power off the
machine automatically, which makes air not enter the ink road system, and printing quality better.
machine automatically, which makes air not enter the ink road system, and printing quality better.
Special computer support, which can make the computer connection and machine more
convenient.UV PRINTING SAMPLES
Product packaging
SIZE: 3500mm×1120mm×1500mm
GROSS WEIGHT: 780KG
PACKAGE: STANDRAND CRATE PACKAGE FOR EXPORT
Company Profile
Certifications
Customer Photos
Why Choose Us
FAQ
01. Do you offer free printing samples?
Yes, we can print some samples according to customer's requirements.
02. What's your delivery time ?
Delivery can be arranged between 5 to 20 working days after the customer make the payment.
03. Once there is something needs to be replaced, what can I do?
We have all the spare parts in stock for the printer.
04. Can we send our technician to your factory for training?
Yes, you are warmly welcome to visit us for free training.
05. How long is the print head life ?
Normally use and maintenance , it can use 2-3 years .
06. lf l have some technical problem, how can you help us to solve it?
Detailed description,photos or video will help our technician analyze the problem and give solution accordingly.
07. What payment method are supported ?
Payment method is TT .
08. How long does the printing images will last outdoors and indoor?
The printing images can last at least 3 years outdoors,and more than 10 years indoor.
09. How about the stability and quality of the printing images?
This UV flatbed printer can used to print on most of medias with best quality, durability,best result.
10. How about the maintenance and aftersales service?
we can provide remote control service and online service for customers.
11. ls there any guarantee for this printer?
Yes, we have guarantee for the printer.We provide one year warranty for all the elec-tronic parts including the main board,driver
board,control board, motor, etc.But there is no warranty for wearing parts like ink pump, printhead, ink filter,and slide block
since they are consumables.
12. How can l install and start to use the printer?
At first, you should read the users' manual or pictires or video to understand the machine.After you get the machine, our
technician will teach you how to install and use-machine by remote control. Whenever you have questions to the machine,you can
contact our technician or me.
13. How will you achieve the warranty?
lf any electronics or a mechanical part is confirmed to be broken,you can send back to repair during warranty time free.
14. what kinds of materials need premier before printing?
Glass,ceramic, metel,acrylic,marble etc.
01. Do you offer free printing samples?
Yes, we can print some samples according to customer's requirements.
02. What's your delivery time ?
Delivery can be arranged between 5 to 20 working days after the customer make the payment.
03. Once there is something needs to be replaced, what can I do?
We have all the spare parts in stock for the printer.
04. Can we send our technician to your factory for training?
Yes, you are warmly welcome to visit us for free training.
05. How long is the print head life ?
Normally use and maintenance , it can use 2-3 years .
06. lf l have some technical problem, how can you help us to solve it?
Detailed description,photos or video will help our technician analyze the problem and give solution accordingly.
07. What payment method are supported ?
Payment method is TT .
08. How long does the printing images will last outdoors and indoor?
The printing images can last at least 3 years outdoors,and more than 10 years indoor.
09. How about the stability and quality of the printing images?
This UV flatbed printer can used to print on most of medias with best quality, durability,best result.
10. How about the maintenance and aftersales service?
we can provide remote control service and online service for customers.
11. ls there any guarantee for this printer?
Yes, we have guarantee for the printer.We provide one year warranty for all the elec-tronic parts including the main board,driver
board,control board, motor, etc.But there is no warranty for wearing parts like ink pump, printhead, ink filter,and slide block
since they are consumables.
12. How can l install and start to use the printer?
At first, you should read the users' manual or pictires or video to understand the machine.After you get the machine, our
technician will teach you how to install and use-machine by remote control. Whenever you have questions to the machine,you can
contact our technician or me.
13. How will you achieve the warranty?
lf any electronics or a mechanical part is confirmed to be broken,you can send back to repair during warranty time free.
14. what kinds of materials need premier before printing?
Glass,ceramic, metel,acrylic,marble etc.
